Eco Solvent Printer,Starjet 7702L (3.2m/1.8m 1440dpi) with New Epson DX7 Heads for Indoor&Outdoor

Product Details:
MT-Starjet 7702L
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Payment Terms:
L/C ,T/T,Western Union
Show Buyers your Ability to Supply:
Production Capacity:
3000 Set/Sets per Year
Delivery Time:
within 7 working days
Wooden case W4350*D930*H730mm

Detailed Product Description

Eco Solvent Printer

MT-Starjet 7702L Eco Solvent Printer (3.2m1440dpi ) with New Epson DX7 Heads for Indoor&Outdoor



Best Selling Starjet Series Eco Solvent Printer!



Now released the latest model Eco Solvent Printer Starjet 7702L (3.2m / 1.8m optional1440dpi) with Upgrade Epson DX7 Heads For Indoor&Outdoor





Item MT-Starjet 7702L Eco Solvent Printer
Print head Two Epson DX7 Micro-Piezo
Number of Nozzles 1440nozzles per head
Color 4 Color: Cyan, Magenta, Yellow, Black
Height of print head
Size of ink-droplet
Printing Width
Speed 3pass 40.5sq.m per hour
4pass 32.0sq.m per hour
6pass 25.0sq.m per hour
8pass 13.8sq.m per hour
Media Width 3300mm
Media take up Yes
Media feeder yes
Media payload 200kgs
Heating System Print Heater and Post heater with PID temperature control temperature range: room temperature to 80 centi degree
Ink Eco Solvent Ink
Water-based Dye Ink
Reactive printing ink
Ink Cartridge 8*350ml continuous ink supply
Rip Software Iprint3.0
Control Software Print Console
Operation System MS Windows XP& Windows7
Interface USB2.0
Power Voltage AC220-240V 50-60HZ or AC110-120V 50-60HZ
Printing Environment Temperature: 20-25 centi degree, Humidity: 40-60%
Printer dimension W4300*D900 * H1250mm
Packing dimension W4350*D930 * H730mm
Net Weight 320kgs
Gross Weight 550kgs




1) Machine body


MeiTu: Strong and rigid machine body


epson head printer details-1.jpg

epson head printer details-2.jpg

epson head printer details-3.jpg



2) Damper and pipes:



MeiTu: Stable and fine connections for the print heads from Meitu company!


epson head printer details-4.jpg

3) Capping station:


MeiTu: Stainless steel capping station from MeiTu company, which is strong and durable to avoid head clogging. Automatic cleaning and wiping system make the printer more friendly to user:


epson head printer details-6.jpg



4) Feeder and take-up systems:



MeiTu: Strong and heavy steel rod can load big roll medias up to 200KG for 3.2m printer. Tensile force media feeding system, which provides stable tensile force for media, makes sure the media feeding is stable, straight and flat. Meanwhile, convenient controls on the rolling speed and torque from Meitu company!


epson head printer details-7.jpgepson head printer details-8.jpgepson head printer details-9.jpg

epson head printer details-10.jpgepson head printer details-12.jpg





5) Printing platform:



Well-equipped printing platform, wide and strong with fine sucking systems to ensure stable and precise printings from MeiTu company!


epson head printer details-14.jpgepson head printer details-15.jpg
