home >> products >> UV Roll To Roll Printer with Epson DX7 Head & 3W UV Lamp

UV Roll To Roll Printer with Epson DX7 Head & 3W UV Lamp

Product Details:
Model:
MT-Starjet UV 7702L
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Shanghai
Payment Terms:
L/C ,T/T,Western Union
Show Buyers your Ability to Supply:
Production Capacity:
3000 Set/Sets per Year
Delivery Time:
within 4 working days
Packaging:
Wooden case W4350*D930*H730mm

Detailed Product Description

Printing Label Machine with Epson DX7 Head & UV Lamp for Small Scale and Prompt Label Printing



The Advantages of MT-Starjet Epson UV printer.



Usually, 1W LED lamp head is very common in the market. We apply imported 3W LED lamp head, which ensures faster drying and better solidification.



The other UV printer’s rip is suitable for image printings, our UV printer rip is more suitable for characters printings. It is designed to make small quantity of characters printings.



Unlike the other UV printers which apply mercury lamp, Our Printing Label Machine apply LED with cold light source which has the advantage of printing low heat resistibility materials. Mercury lamp has short lifetime because it will easily get burned. Moreover, its high temperature cannot print on low heat resistibility materials.





Item

MT-Starjet UV 7702L

Printing Label Machine /UV Printer

Print head

Two Epson DX7 Micro-Piezo

Number of Nozzles

1440nozzles per head

Color

4 Color: Cyan, Magenta, Yellow, Black

Height of print head

2-5mm

Size of ink-droplet

1.5pl-21pl

Printing Width

3.2m

Speed

3pass

52.0 sq.m per hour

4pass

41.6 sq.m per hour

6pass

32.5 sq.m per hour

8pass

17.9 sq.m per hour

Media Width

3300mm

Media take up

Yes

Media feeder

yes

Media payload

200kgs

Heating System

3W LED Lamp

Ink

UV Ink

Ink Cartridge

8*350ml continuous ink supply

Rip Software

Iprint3.0

Control Software

Print Console

Operation System

MS Windows XP& Windows7

Interface

USB2.0

Power Voltage

AC220-240V 50-60HZ or AC110-120V 50-60HZ

Printing Environment

Temperature: 20-25 centi degree, Humidity: 40-60%

Printer dimension

W4300*D900 * H1250mm

Packing dimension

W4350*D930 * H730mm

Net Weight

320kgs

Gross Weight

550kgs





Sample:





1) LED Lamp: MT-Starjet Series UV Printer apply LED with cold light source which has the advantage of printing low heat resistibility materials



UV Lamp.jpg





2) Machine body



MeiTu: Strong and rigid machine body



epson head printer details-1.jpg

epson head printer details-2.jpg

epson head printer details-3.jpg





3) Damper and pipes:





MeiTu: Stable and fine connections for the print heads from Meitu company!



epson head printer details-4.jpg


4) Capping station:



MeiTu: Stainless steel capping station from MeiTu company, which is strong and durable to avoid head clogging. Automatic cleaning and wiping system make the printer more friendly to user:



epson head printer details-6.jpg





5) Feeder and take-up systems:





MeiTu: Strong and heavy steel rod can load big roll medias up to 200KG for 3.2m printer. Tensile force media feeding system, which provides stable tensile force for media, makes sure the media feeding is stable, straight and flat. Meanwhile, convenient controls on the rolling speed and torque from Meitu company!



epson head printer details-7.jpgepson head printer details-8.jpgepson head printer details-9.jpg

epson head printer details-12.jpg









5) Printing platform:





Well-equipped printing platform, wide and strong with fine sucking systems to ensure stable and precise printings from MeiTu company!



epson head printer details-14.jpgepson head printer details-15.jpg
