home >> products >> Digital Textile Printer,with DX5/DX7 Head (1.8 &3.2meter,1440dpi) for roll to roll fabric printing

Digital Textile Printer,with DX5/DX7 Head (1.8 &3.2meter,1440dpi) for roll to roll fabric printing

Product Details:
MT-Starjet 7702
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Payment Terms:
L/C ,T/T,Western Union
Show Buyers your Ability to Supply:
Production Capacity:
3000 Set/Sets per Year
Delivery Time:
within 7 working days
Wooden case W2840*D900*H1250mm for Printer, W2780*D870*H1330mm for Sublimation Heater

Detailed Product Description

Digital Textile Printer :


www.mtutech.com / www.solventprinter.cn


MT-Starjet Series Digital Textile Printer have been used most field such as advertisement printing textile digital printing, carpet digital printing, windows curtain digital printing and interior decoration printing and flax printing widely.

It is simple and leaves out deat transfer process one person can operates with high efficiency and short time.
Low cost and no need of any kind of interval paper, bearing the highest cost performance.
Adopting the most advanced thermal energy technology, Low power consumption, saves electricity, and conserve energy cost.
Brand-New Printing Concert, Unnecessarily handmade plate making, printing directly.
Rapid speed and various printer to choose

Product Model

MT-Starjet 5.0

Digital Textile Printer

MT-Starjet 5

Digital Textile Printer

Printing Technology

The Epson DX5 Micro Piezo Technology

Number of nozzles

1440 nozzles per head

2880 nozzles per 2 head

Ink Colors

4colors : Cyan, Magenta, Yellow, Black

Printer Head height

Adjustable 2~5mm


1440dpi (Max)

Ink droplet size

1.5-21 pl

Printing width

1.8 M (Max)


High speed Mode: 12 m2/hour

High speed Mode: 22.5m2/hour

Standard Mode: 7.7 m2/hour

Standard Mode: 14.5 m2/hour

Photo Mode:5.7 m2/hour

Photo Mode:11.2 m2/hour

Heating System

The heaters for front and center platform separately. PID temperature control


Temperature range: room temperature~80°C

Drying system

External fan


Width: 1.9 M (max media width

Media feeding mode: Automatic feeder

Automatic take up (optional)

self-adhesive paper, PVC, mesh fabric, textile, PVC flex banner, Self Adhesive Vinyl , paper, fabric, leather and etc.


Sublimation Ink

Reactive Ink

Acid Ink

Ink Cartridge: 8 x 350ml

RIP software

Photoprint Rip Software

Supported Image format: Tiff, Jpeg and other common image formats

PostScript file process (Optional)

Color Mode: RGB or CMYK

Control Software

Control Software MT-Starjet5 Control Software (Cn/En)


USB 2.0,RS232

Operating System

Windows XP


AC 220-240V 50/60HZ or AC 110-120V 50/60HZ

Power consumption Power: 1KW (Max), 300W (Printing)

Power consumption

Ambient temperature: 20-25°C


Humidity: 40~70 % Non-condensing


Printer Dimension(W x D x H) 2,840 x 900 x 1,250 mm (Bracket Included)

Packing Dimension(W x D x H): 3,000 x 930 x 730mm (Bracket Included)


Net Weight: 220 kg (Bracket Included)

Gross Weight: 300 kg (Bracket Included)


TEXTILE PRINTER-showroom-1.jpg
